AquaForce® - Variable-speed air-cooled screw liquid chiller using HFO R-1234ze refrigerant
30KAVZE

Refrigerant : R-1234ze

Compressor : screw variable-speed

Nominal cooling capacity : 370-1350 kW

The AquaForce® Vision 30KAVZE liquid chillers with Greenspeed® Intelligence are the premium solution for commercial and industrial applications where installers, consultants and building owners require superior reliability and optimal performances, especially at part load.

  • Outstanding performance
  • Low sound levels
  • Intelligence and connectivity
  • Environmentally responsible
  • Wide range of applications
  • Simple installation and maintenance

The range is available in 4 efficiency levels:

  • 30KAVZE standard unit
  • 30KAVZE with EC fans (option 17) - enhances the seasonal energy efficiency
  • 30KAVZE with High Energy Efficiency (option 119) - equipped with additional heat exchange surface to deliver optimum performance at both full load and part load
  • 30KAVZE with High Energy Efficiency+ (option 119+) - equipped with EC fans and additional heat exchange surface to provide the highest possible seasonal energy efficiency

Outstanding energy performance

  • 2nd generation of Carrier high-efficiency variable-speed twin-screw compressors with built in volume index control (Vi) valve for both optimal full and part load performance
  • Variable-speed Flying Bird™ fans with EC motor minimizing power consumption
  • Novation® aluminum condenser with high-efficiency micro-channel coils technology
  • Optimized electrical performance
  • Hydraulic module with variable-speed dual pump
  • Smart energy monitoring

Built-in reliability and easy servicing

  • Screw compressors are industrial-type with oversize bearings and motor cooled by suction gas
  • Variable-speed fans
  • Novation® aluminum micro-channel heat exchangers (MCHE) with high corrosion resistance
  • Flooded evaporator with mechanically cleanable water tubes
  • Two independent refrigerant circuits to secure partial cooling
  • Auto-adaptive control
  • Exceptional endurance tests

Minimized operating sound levels

  • Greenspeed® Intelligence, featuring variable-speed screw compressors and condenser fans, minimizes noise levels at part load operation
  • New generation of Carrier 06Z variable-speed twin screw compressor with integrated resonator array
  • 6th generation of silent Flying Bird™ fans
  • 4 sound levels to match the most sensitive environments

Easy and fast installation

  • Built-in variable speed pumps up to 800 kW
  • Compact units for easy transportation and installation
  • Simplified electrical connections
  • Simplified water connections
  • Fast commissioning

Environmental care

  • Automatic energy meter
  • PUREtec™ R-1234ze long-term refrigerant solution
  • 40% less refrigerant allowed by the micro-channel technology
  • Leak tight refrigerant circuits
  • Refrigerant leak alert
  • Refrigerant leak detection (option)

Designed to support Green Building Design

  •  LEED® (Leadership in Energy and Environmental Design) certification

New generation of Carrier 06Z variable-speed twin screw compressor

  • Twin screw compressor optimized for variable speed operation
  • Separate air-cooled inverter drive for increased reliability
  • Integrated Resonator Array (IRA) to reduce the sound level by up to 6 dB(A) when compared with previous 06T generation
  • Integrated Check Valve for quiet shutdown
  • Bearing life exceeding 100 000 hours
  • A dedicated oil separator is installed at the discharge of each compressor to ensure maximum oil return
  • Volume index control (Vi) valve provides a reliable method of adjusting the compression ratio to better match system demand
  • Screw compressors work on the positive displacement principle to compress gas to a higher pressure. As a result, if there is an unusually high pressure in the condenser, the compressor does not switch off, but continues operation at reduced capacity (unloaded mode)
  • The silencer in the oil separator line considerably reduces discharge gas pulsations for much quieter operation
carrier-06Z-screw-compressor-for-chillers
  • 30KAVZE : SEER LT 12/7 up to 5.3 and SEPR HT 12/7 up to 6.52
  • 30KAVZE : with EC fan motors (option 17) SEER LT is up to 5.39 and SEPR HT up to 6.6
  • 30KAVZE : with High Energy Efficiency (option 119) SEER LT is up to 5.48 and SEPR HT up to 6.84
  • 30KAVZE : with High Energy Efficiency+ (option 119+) SEER LT is up to 5.5 and SEPR HT up to 6.95

SmartVu™ control

  • Intuitive and user-friendly, coloured, 7" interface
  • 10 languages available
  • Easy access to the controller box
  • Password protection
  • Night-mode
  • Energy management
carrier-aquaforce-air-cooled-chiller-30KAV-30KAVP-control-screen

Remote management as standard

  • Easily accessed from the internet
  • Multiple remote control, monitoring and diagnostic possibilities
  • Optional communication gateways
  • Start/Stop of the machine
  • Dual set-point management
  • Water pump control

Remote management (EMM option)

  • Extended remote control possibilities: room temperature, set-point reset, etc.
  • EC fans
  • High energy efficiency and High energy efficiency+
  • Low and high pressure variable-speed dual pumps
  • Low noise and very low noise
  • Side enclosure panels and grilles
  • High ambient temperature operation up to 55°C
  • IP 54 control box
  • Evaporator and pumps aluminum jacket
  • Service valves
  • BACnet, JBus and Lon communication interfaces
  • Wireless connectivity for remote energy monitoring
  • 50+ Boosted total heat recovery
  • 294 Electric energy meter
  • 295+ ultra fast capacity recovery
  • 329 PM Motor
  • 333 Neutral IT system

The range is available in 4 efficiency levels:

  • 30KAVZE standard unit
  • 30KAVZE with EC fans (option 17) - enhances the seasonal energy efficiency
  • 30KAVZE with High Energy Efficiency (option 119) - equipped with additional heat exchange surface to deliver optimum performance at both full load and part load
  • 30KAVZE with High Energy Efficiency+ (option 119+) - equipped with EC fans and additional heat exchange surface to provide the highest possible seasonal energy efficiency

Outstanding energy performance

  • 2nd generation of Carrier high-efficiency variable-speed twin-screw compressors with built in volume index control (Vi) valve for both optimal full and part load performance
  • Variable-speed Flying Bird™ fans with EC motor minimizing power consumption
  • Novation® aluminum condenser with high-efficiency micro-channel coils technology
  • Optimized electrical performance
  • Hydraulic module with variable-speed dual pump
  • Smart energy monitoring

Built-in reliability and easy servicing

  • Screw compressors are industrial-type with oversize bearings and motor cooled by suction gas
  • Variable-speed fans
  • Novation® aluminum micro-channel heat exchangers (MCHE) with high corrosion resistance
  • Flooded evaporator with mechanically cleanable water tubes
  • Two independent refrigerant circuits to secure partial cooling
  • Auto-adaptive control
  • Exceptional endurance tests

Minimized operating sound levels

  • Greenspeed® Intelligence, featuring variable-speed screw compressors and condenser fans, minimizes noise levels at part load operation
  • New generation of Carrier 06Z variable-speed twin screw compressor with integrated resonator array
  • 6th generation of silent Flying Bird™ fans
  • 4 sound levels to match the most sensitive environments

Easy and fast installation

  • Built-in variable speed pumps up to 800 kW
  • Compact units for easy transportation and installation
  • Simplified electrical connections
  • Simplified water connections
  • Fast commissioning

Environmental care

  • Automatic energy meter
  • PUREtec™ R-1234ze long-term refrigerant solution
  • 40% less refrigerant allowed by the micro-channel technology
  • Leak tight refrigerant circuits
  • Refrigerant leak alert
  • Refrigerant leak detection (option)

Designed to support Green Building Design

  •  LEED® (Leadership in Energy and Environmental Design) certification

New generation of Carrier 06Z variable-speed twin screw compressor

  • Twin screw compressor optimized for variable speed operation
  • Separate air-cooled inverter drive for increased reliability
  • Integrated Resonator Array (IRA) to reduce the sound level by up to 6 dB(A) when compared with previous 06T generation
  • Integrated Check Valve for quiet shutdown
  • Bearing life exceeding 100 000 hours
  • A dedicated oil separator is installed at the discharge of each compressor to ensure maximum oil return
  • Volume index control (Vi) valve provides a reliable method of adjusting the compression ratio to better match system demand
  • Screw compressors work on the positive displacement principle to compress gas to a higher pressure. As a result, if there is an unusually high pressure in the condenser, the compressor does not switch off, but continues operation at reduced capacity (unloaded mode)
  • The silencer in the oil separator line considerably reduces discharge gas pulsations for much quieter operation
carrier-06Z-screw-compressor-for-chillers
  • 30KAVZE : SEER LT 12/7 up to 5.3 and SEPR HT 12/7 up to 6.52
  • 30KAVZE : with EC fan motors (option 17) SEER LT is up to 5.39 and SEPR HT up to 6.6
  • 30KAVZE : with High Energy Efficiency (option 119) SEER LT is up to 5.48 and SEPR HT up to 6.84
  • 30KAVZE : with High Energy Efficiency+ (option 119+) SEER LT is up to 5.5 and SEPR HT up to 6.95

SmartVu™ control

  • Intuitive and user-friendly, coloured, 7" interface
  • 10 languages available
  • Easy access to the controller box
  • Password protection
  • Night-mode
  • Energy management
carrier-aquaforce-air-cooled-chiller-30KAV-30KAVP-control-screen

Remote management as standard

  • Easily accessed from the internet
  • Multiple remote control, monitoring and diagnostic possibilities
  • Optional communication gateways
  • Start/Stop of the machine
  • Dual set-point management
  • Water pump control

Remote management (EMM option)

  • Extended remote control possibilities: room temperature, set-point reset, etc.
  • EC fans
  • High energy efficiency and High energy efficiency+
  • Low and high pressure variable-speed dual pumps
  • Low noise and very low noise
  • Side enclosure panels and grilles
  • High ambient temperature operation up to 55°C
  • IP 54 control box
  • Evaporator and pumps aluminum jacket
  • Service valves
  • BACnet, JBus and Lon communication interfaces
  • Wireless connectivity for remote energy monitoring
  • 50+ Boosted total heat recovery
  • 294 Electric energy meter
  • 295+ ultra fast capacity recovery
  • 329 PM Motor
  • 333 Neutral IT system
carrier-video-screenshot-30kav_hfo_en
AquaForce® Vision 30KAV range
available with HFO
AquaForce® Vision is available with PUREtec™ refrigerant, as its premium variable-speed air-cooled screw chiller using low Global Warming Potential HFO R-1234ze refrigerant. The unit balances environmental responsibility with outstanding performance.
carrier-innovation-puretec-logo
30KAVZE with
PUREtec™ refrigerant
Carrier meeting the challenge of efficiency and climate change with PUREtec™ range that will not only protect the ozone layer but also have a very low global warming impact.
carrier-video-screenshot-30kav_low_brine_en
The AquaForce® 30KAV range
available with Low Brine option
The AquaForce® 30KAV range is available with Low Brine option. Low-temperature chilled water production up to -15 °C with very low pressure drops fulfills the process applications specifics requirements.
carrier-video-screenshot-30kav_heat_recovery_en
The AquaForce® 30KAV range
available with Heat Recovery options
The AquaForce® 30KAV range is available with Heat recovery options to offer industrial process applications a more sustainable heating solution using renewable energy.
carrier-video-screenshot-30kav_performance_en
The AquaForce® Vision 30KAVP, a premium variable-speed air-cooled screw chiller reaches a never before seen seasonal energy efficiency ratio rating of 5.6, which is 25% above the Ecodesign 2021 requirements.

Carrier’s AquaForce Vision 30KAVP covers cooling capacities from 500 kW up to 1100 kW and achieves premium energy performance, even compared to oil-free chillers with magnetic levitation compressors. Combined with EC variable-speed fans, the twin screw compressor equipped with cutting-edge permanent magnet motor technology offers optimal operation at part load, compared to traditional compressor technologies. The permanent magnet motor ensures a constant efficiency over the entire operating range.
