Supra 850
Supra 850
Solutions for all your distribution needs
SUPRA range performance for refrigerated trucks
BENEFITS
- Constant evaporator airflow
- Robust design
- High reliability
- Extreme low-noise capabilities
- High cooling performance
Developed for distribution environments with multiple doors openings, rely on the unmatched performance of the SUPRA range in your challenging operation.
The SUPRA range achieves superior pull-down and accurate temperature control at all set points. This performance is supported by a large range of evaporators with electric fans providing constant airflow independent of engine speed. Available in multi-temperature throughout the range, SUPRA offers enhanced load protection for all truck applications.
ROBUST DESIGN
Building on hundreds of thousands of operating hours, SUPRA demonstrates a robust design both for aesthetics (strong composite material) and components (easy start) to extend the unit lifetime and reduce downtime. Maintenance time is also optimised thanks to easy accessibility.
BENEFITS
- Constant evaporator airflow
- Robust design
- High reliability
- Extreme low-noise capabilities
- High cooling performance
Refrigeration Capacity
(System net cooling capacity under A.T.P. Conditions at 30° C ambient)
| Capacity on engine power 0°C (W) | 7 800 |
| Capacity on engine power -20°C (W) | 4 900 |
| Capacity on electrical stand by 0°C (W) | 6 450 |
| Capacity on electrical stand by -20°C (W) | 4 240 |
Heating Capacity
| Diesel High speed 18°C/-18°C (W) | 3 360 |
| Standby 18°C/-18°C (W) | 1 765 |
Airflow
(High speed engine operation)
| (AMCA 21085) m3/hr | 2 500 |
Weight
(Including battery)
| S version (Standard) | 461 kg |
| T version (Low noise) | 464 kg |
| X version (Silent) | 466 kg |
Engine
(n° of cylinders - cm3)
| Model | CT3-44TV |
| Displacement | 719 cm3 |
| n° of cylinders | 3 |
| Maintenance Interval | 750/1000 hrs |
Compressor
| Model | 05K4 |
| Displacement | >400 cm3 |
| n° of cylinders | 4 |
Electrical Stand by Motor
| Voltage / Phase / Frequency | 230/400/3/50 Hz
240/460/3/60 Hz |
| Rating | 4,8 kW |
Refrigerant Charge
| Type | R-404A, R-452A |
| Charge | 6,8 kg |
Sound Pressure
| Standard | Low Noise | Silent | |
| High speed | 68,7 dBA | 66 dBA | 64,6 dBA |
| Low speed | 66,3 dBA | 62,1 dBA | 61,9 dBA |
| Standby | 59,7 dBA | 55 dBA |
- |
Unit
| Dimensions | 888 x 1823 x 629 mm |
| Body opening | L 1245 x H 350 mm |
