X4™-7300 X4
X4™-7300
X4
Smarter performance, smarter control, designed for extreme operations.
BENEFITS
- Maximizing uptime
- Protecting cargo
- Ensuring sustainability
- Road only
Built upon the proven X2™ platform, the X4™ unit sets the bar even higher as the new industry standard for refrigeration performance and control.
Featuring micro channel heat exchanger coils, Carrier’s X4™ platform boosts the performance-to-power ratio. By introducing enhanced power-management algorithms to communicate with a smarter engine, capacity is increased by 3% up to 6%* to 20 200 Watts.
BENEFITS
- Maximizing uptime
- Protecting cargo
- Ensuring sustainability
- Road only
Refrigeration Capacity
System net cooling capacity under A.T.P. Conditions at 30°C ambient
|
Capacity on engine power 0°C |
20 200 W |
|
Capacity on engine power -20°C |
10 600 W |
Heating Capacity
|
Standby 18°C/-18°C |
9 900 W |
Airflow
on high speed engine operation
|
(AMCA 21085) |
5 200 m3/hr |
Weight
Including battery
|
R version (Road) |
753 kg |
102 dB |
Engine
|
Model |
CT4-134 TV |
|
Displacement |
2230 cm3 |
|
n° of cylinders |
4 |
|
Maintenance Interval |
3000 hrs |
Compressor
|
Model |
05G |
|
Displacement |
655 cm3 |
|
n° of cylinders |
6 |
Refrigerant
|
Type |
R-404A |
|
Charge |
6,8 kg |
Generic
|
Dimensions (D x W x H) |
1 940 x 2 177 x 579 mm |
|
Body opening |
L 1697 x H 1168 mm |
Built upon the proven X2™ platform, the X4™ unit sets the bar even higher as the new industry standard for refrigeration performance and control.
Featuring micro channel heat exchanger coils, Carrier’s X4™ platform boosts the performance-to-power ratio. By introducing enhanced power-management algorithms to communicate with a smarter engine, capacity is increased by 3% up to 6%* to 20 200 Watts.
BENEFITS
- Maximizing uptime
- Protecting cargo
- Ensuring sustainability
- Road only
Refrigeration Capacity
System net cooling capacity under A.T.P. Conditions at 30°C ambient
|
Capacity on engine power 0°C |
20 200 W |
|
Capacity on engine power -20°C |
10 600 W |
Heating Capacity
|
Standby 18°C/-18°C |
9 900 W |
Airflow
on high speed engine operation
|
(AMCA 21085) |
5 200 m3/hr |
Weight
Including battery
|
R version (Road) |
753 kg |
102 dB |
Engine
|
Model |
CT4-134 TV |
|
Displacement |
2230 cm3 |
|
n° of cylinders |
4 |
|
Maintenance Interval |
3000 hrs |
Compressor
|
Model |
05G |
|
Displacement |
655 cm3 |
|
n° of cylinders |
6 |
Refrigerant
|
Type |
R-404A |
|
Charge |
6,8 kg |
Generic
|
Dimensions (D x W x H) |
1 940 x 2 177 x 579 mm |
|
Body opening |
L 1697 x H 1168 mm |
