Supra 450
Supra 450
Solutions for all your distribution needs
SUPRA range performance for refrigerated trucks
BENEFITS
- Constant evaporator airflow
- Robust design
- High reliability
- Extreme low-noise capabilities
- High cooling performance
Developed for distribution environments with multiple doors openings, rely on the unmatched performance of the SUPRA range in your challenging operation.
The SUPRA range achieves superior pull-down and accurate temperature control at all set points. This performance is supported by a large range of evaporators with electric fans providing constant airflow independent of engine speed. Available in multi-temperature throughout the range, SUPRA offers enhanced load protection for all truck applications.
ROBUST DESIGN
Building on hundreds of thousands of operating hours, SUPRA demonstrates a robust design both for aesthetics (strong composite material) and components (easy start) to extend the unit lifetime and reduce downtime. Maintenance time is also optimised thanks to easy accessibility.
BENEFITS
- Constant evaporator airflow
- Robust design
- High reliability
- Extreme low-noise capabilities
- High cooling performance
Refrigeration Capacity
(System net cooling capacity under A.T.P. Conditions at 30°C ambient)
| Capacity on engine power 0°C (W) | 4 365 |
| Capacity on engine power -20°C (W) | 2 515 |
| Capacity on electrical stand by 0°C (W) | 3 810 |
| Capacity on electrical stand by -20°C (W) | 2 240 |
Heating Capacity
| Diesel High speed 18°C/-18°C (W) | 1 520 |
| Standby 18°C/-18°C (W) | 775 |
Airflow
(High speed engine operation)
| (AMCA 21085) m3/hr | 1 590 |
Weight
(Including battery)
| S version (Standard) | 340 kg |
| T version (Low noise) | 343 kg |
Engine
| Model | CT2-29TV |
| Displacement | 479 cm3 |
| n° of cylinders | 2 |
| Maintenance Interval | 500/750 hrs |
Compressor
| Model | Carrier 160 |
| Displacement | 163 cm3 |
| n° of cylinders | 6 |
Electrical Stand by Motor
| Voltage / Phase / Frequency | 230/400/3/50 Hz
240/460/3/60 Hz |
| Rating | 3,6 kW |
Refrigerant
| Type | R-404A |
| Charge | 3,2 kg |
Sound Pressure
| Standard | Low Noise | |
| High speed | 68 dBA | 66,1 dBA |
| Low speed | 63,6 dBA | 62,4 dBA |
| Standby | 59,8 dBA | 58,8 dBA |
Unit
| Dimensions | 825 x 1823 x 555 mm |
| Body opening | L 800 x H 345 mm |
Developed for distribution environments with multiple doors openings, rely on the unmatched performance of the SUPRA range in your challenging operation.
The SUPRA range achieves superior pull-down and accurate temperature control at all set points. This performance is supported by a large range of evaporators with electric fans providing constant airflow independent of engine speed. Available in multi-temperature throughout the range, SUPRA offers enhanced load protection for all truck applications.
ROBUST DESIGN
Building on hundreds of thousands of operating hours, SUPRA demonstrates a robust design both for aesthetics (strong composite material) and components (easy start) to extend the unit lifetime and reduce downtime. Maintenance time is also optimised thanks to easy accessibility.
BENEFITS
- Constant evaporator airflow
- Robust design
- High reliability
- Extreme low-noise capabilities
- High cooling performance
Refrigeration Capacity
(System net cooling capacity under A.T.P. Conditions at 30°C ambient)
| Capacity on engine power 0°C (W) | 4 365 |
| Capacity on engine power -20°C (W) | 2 515 |
| Capacity on electrical stand by 0°C (W) | 3 810 |
| Capacity on electrical stand by -20°C (W) | 2 240 |
Heating Capacity
| Diesel High speed 18°C/-18°C (W) | 1 520 |
| Standby 18°C/-18°C (W) | 775 |
Airflow
(High speed engine operation)
| (AMCA 21085) m3/hr | 1 590 |
Weight
(Including battery)
| S version (Standard) | 340 kg |
| T version (Low noise) | 343 kg |
Engine
| Model | CT2-29TV |
| Displacement | 479 cm3 |
| n° of cylinders | 2 |
| Maintenance Interval | 500/750 hrs |
Compressor
| Model | Carrier 160 |
| Displacement | 163 cm3 |
| n° of cylinders | 6 |
Electrical Stand by Motor
| Voltage / Phase / Frequency | 230/400/3/50 Hz
240/460/3/60 Hz |
| Rating | 3,6 kW |
Refrigerant
| Type | R-404A |
| Charge | 3,2 kg |
Sound Pressure
| Standard | Low Noise | |
| High speed | 68 dBA | 66,1 dBA |
| Low speed | 63,6 dBA | 62,4 dBA |
| Standby | 59,8 dBA | 58,8 dBA |
Unit
| Dimensions | 825 x 1823 x 555 mm |
| Body opening | L 800 x H 345 mm |
certified
